1.5X sensor*, Max 150mbps bitrate, Super-high Resolution,Professional quality
* This product uses a 1 / 1.7" sensor, whose photosensitive area is 1.44 times that of 1 / 2.3"sensor
1. Adde 5.7K 60fps (8bit & 10bit) video recording format
2. Added 8K 1fps live streaming specification (for QooCam 8K Enterprise only)
* This version only supports firmware flashing upgrade, OTA upgrade is not supported. For flashing steps, please refer to the flashing upgrade guide included in the firmware package.
1. Adde 5.7K 60fps (8bit & 10bit) video recording format
7680*3840, 4 times the resolution of 4K
15FPS/20FPS
Can‘t play video smoothly
30FPS
Smoothly
8K 30FPS is becoming the standard for panoramic live streaming.
With two 1 / 1.7" 20MP sensors, QooCam 8K Enterprise’s photosensitive area is 1.5 times that of 1 / 2.3"sensor. Its customized lenses and higher signal-to-noise ratio also contribute to clearer image with more details contained, especially in complex light situations.
Excellent image with more details
Film-level ISP adjustment for more natural and real images
Higher dynamic range for various light conditions
Built-in noise reduction algorithm for live streaming
Clear image in low light
Sensor
MP
camera sensitive area
5G Ethernet port allows easy connection with 5G network.
In-camera realtime live streaming, no need for an expensive PC computer.
Supporting rtmp, rtmps and rtsp
Camera
Cloud
VR Play
1Turn on camera
2Plug in Ethernet cable
3Live streaming starts
*It is for QooCam 8K Enterprise, 5G CPE is optional 700g.
ISO
White Balance
Encoding format
Bitrate
Resolution
2.4" touchscreen of the camera to preview & parameter adjustment
App to preview & parameter adjustment via WiFi
The camera will turn on and start live streaming once it is plugged in, and instantly stop when it is powered off, convenient for live streaming in scenic resorts, factories, outdoor, etc.
With a rainproof case, QooCam 8K Enterprise can reliably and stably transmit live streaming data for long time even if it rains outdoors.
You can put your logo or other image on the nadir, useful for displaying information.
Professional image quality and sound quality for a more infectious and immersive live streaming experience.
Better image quality and more flexibility in post production
10bit video provides 4 times the color depth compared to 8bit video
12bit images contain image information 16 times compared to 8bit.
*Only video recording supports these features
Support multi-protocol, RTMP and RTMPS
Any180° view from 360° live broadcast
Any Resolution up to 7680*3840
Any Bitrate up to 150Mbps
QooCam LiveReal-time color correction for the stream. Supports up to two picture-in-picture.
Multiple type of pictures is available, such as local video, local picture, HDMI capture, and RTMP live streaming.
*The QooCam Live fully functional trial version is available before purchase
Medical
Education
Tourism
News
Judicature
Enterprise
Performing arts
Race
Aerial photography
Security
| Live Mode | Cam streaming , phone streaming |
| Supporting Protocol | rtsp, rtmp, rtmps |
| Resolution | 8K: 7680*3840, 5.7K: 5760x2880, 4K: 3840*1920 |
| Lens Adjustments | Real-time automatic/manual exposure and white balance adjustments: EV, Shutter, ISO, Color temperature |
| Live Preview | Camera real-time 360 preview |
| Live Bitrate | Max 150Mb/s |
| Code Format | H.264、H.265 |
| Image Stitching | Real-time stitching |
| Image Stabilization | SuperSteady |
| Lens | F2.0，FOV：200° |
| Image sensor size | 1/1.7 inch BSI-COMS 20MP |
| Video (360) | 7680*3840@30fps 8/10bit, 5760x2880@60fps 8/10bit, 3840*1920@120fps 8/10bit |
| Photo (360) | 7680*3840, 12bit DNG(RAW),DNG8(16bit output) |
| Video format | MP4 |
| Audio format | PCM |
| Photo format | JPG, DNG |
| Video bit rate | Up to 200Mbps |
| Video code | H.264, H.265 |
| IMU | 6-axis IMU |
| Screen | 2.4 inch colorful touch screen |
| Photo mode | Still image, Timed photos, DNG8, Time lapse photo |
| Video mode | Video, Slow motion, Sports mode |
| Live streaming | 8K/4K 360° Live |
| EV | -2EV ~ +2EV |
| Exposure | EV (auto): -2EV ~ +2EV |
| Manual Mode: Photo: 1/6400s-1s DNG8: 1/6400s-1s Video: 30fps:1/6400s-1/30s 120fps:1/6400s-1/120s ISO: 100-6400 | |
| Sports Mode: There are two choices to control the maximum shutter time: Mode 1, Mode 2. For 50Hz, Mode 1 is 1/50s, Mode 2 is 1/100s For 60Hz, Mode 1 is 1/60s, Mode 2 is 1/120s Sports EV:{ -2.0EV to +2.0 EV} | |
| White Balance | AWB, Fluorescent, Incandescent, Cloudy, Daylight |
| Color | Black |
| Weight | Approx. 275g |
| External Dimensions | 179mm*57mm*33mm |
| WIFI | 2.4G/5G |
| External interface | USB Type-C,LAN |
| Storage | Internal 64GB EMMC |
| SD card | Support external TF Card (up to 256GB), U3 card is recommended |
| Mic | Build-in Mic |
| WAN/LAN | RJ45 |
| Line-in | 3.5mm |
| Capacity | 3000mAh.Approx. 90 minutes for 8K@30fps or 4K@120fps video recording. 360° Live:90 minutes. |
| Charging method | USB-PD Fast Charge with 3A or above is commended; |
| Usage temperature range | -20°C – 40°C |
